Item	Dimeter	Type/dopant	Orientaion	Coating	wavefront distortion	Parallelism	Reflectivity	dopant element concentration	Flatness	Surface/Roughness	Geometric parameter
GGG	25.4mm 50.8mm 76.5mm 100mm	Intrinsic	<100><110><111>	AR/HR/PR	≤0.15入/25mm	10 arc sec	1.95	0.5~1.2(±0.1)atm%	< λ/10 @ 632.8 nm	polished/etched polished/polished	TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um
(Nd:GGG)	25.4mm 50.8mm 76.5mm 100mm	Nd(钕)	<100><110><111>	AR/HR/PR	≤0.15入/25mm	10 arc sec	1.95	0.5~1.2(±0.1)atm%	< λ/10 @ 632.8 nm	polished/etched polished/polished	TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um
(Yb:GGG)	25.4mm 50.8mm 76.5mm 100mm	镱(Yb)	<100><110><111>	AR/HR/PR	≤0.15入/25mm	10 arc sec	1.95	0.5~1.2(±0.1)atm%	< λ/10 @ 632.8 nm	polished/etched polished/polished	TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um
YAG	25.4mm 50.8mm 76.5mm 100mm	Intrinsic	<100><110><111>	AR/HR/PR	≤0.125入/25mm	10 arc sec	1.82	0.5~1.2(±0.1)atm%	< λ/10 @ 632.8 nm	polished/etched polished/polished	TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um
(Nd:YAG )	25.4mm 50.8mm 76.5mm 100mm	Nd(钕)	<100><110><111>	AR/HR/PR	≤0.125入/25mm	10 arc sec	1.82	0.5~1.2(±0.1)atm%	< λ/10 @ 632.8 nm	polished/etched polished/polished	TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um
(Er:YAG )	25.4mm 50.8mm 76.5mm 100mm	Er	<100><110><111>	AR/HR/PR	≤0.125入/25mm	10 arc sec	1.82	0.5~1.2(±0.1)atm%	< λ/10 @ 632.8 nm	polished/etched polished/polished	TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um
(Yb:YAG )	25.4mm 50.8mm 76.5mm 100mm	镱(Yb)	<100><110><111>	AR/HR/PR	≤0.125入/25mm	10 arc sec	1.82	0.5~1.2(±0.1)atm%	< λ/10 @ 632.8 nm	polished/etched polished/polished	TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um
YVO4	25.4mm 50.8mm 76.5mm 100mm	Intrinsic	<100><110><111>	AR/HR/PR	≤0.25入/25mm	10 arc sec	2.1	0.5~1.2(±0.1)atm%	< λ/10 @ 632.8 nm	polished/etched polished/polished	TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um
(Nd:YVO4)	25.4mm 50.8mm 76.5mm 100mm	Nd(钕)	<100><110><111>	AR/HR/PR	≤0.25入/25mm	10 arc sec	2.1	0.5~1.2(±0.1)atm%	< λ/10 @ 632.8 nm	polished/etched polished/polished	TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um
(Er:YVO4)	25.4mm 50.8mm 76.5mm 100mm	Er	<100><110><111>	AR/HR/PR	≤0.25入/25mm	10 arc sec	2.1	0.5~1.2(±0.1)atm%	< λ/10 @ 632.8 nm	polished/etched polished/polished	TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um
(Yb:YVO4)	25.4mm 50.8mm 76.5mm 100mm	镱(Yb)	<100><110><111>	AR/HR/PR	≤0.25入/25mm	10 arc sec	2.5	0.5~1.2(±0.1)atm%	< λ/10 @ 632.8 nm	polished/etched polished/polished	TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um
磷酸钛氧钾(KTP)	25.4mm 50.8mm 76.5mm 100mm		X Y Z cut	AR/HR/PR	> λ/8 @ 633 nm	10 arc sec	2.1	0.5~1.2(±0.1)atm%	< λ/10 @ 632.8 nm	polished/etched polished/polished	TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um
KDP(KH2 PO4)	25.4mm 50.8mm 76.5mm 100mm		X Y Z cut	AR/HR/PR	> λ/8 @ 633 nm	10 arc sec	2.1	0.5~1.2(±0.1)atm%	< λ/10 @ 632.8 nm	polished/etched polished/polished	TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um
Lithium Triborate (LiB3O5 , LBO)	25.4mm 50.8mm 76.5mm 100mm		X Y Z cut	AR/HR/PR	> λ/8 @ 633 nm	10 arc sec	2.1	0.5~1.2(±0.1)atm%	< λ/10 @ 632.8 nm	polished/etched polished/polished	TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um
Beta-Barium Borate (β-BaB2O4,BBO)	25.4mm 50.8mm 76.5mm 100mm		X Y Z cut	AR/HR/PR	> λ/8 @ 633 nm	10 arc sec	2.1	0.5~1.2(±0.1)atm%	< λ/10 @ 632.8 nm	polished/etched polished/polished	TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um
BiB3O6 (BIBO)	25.4mm 50.8mm 76.5mm 100mm		X Y Z cut	AR/HR/PR	> λ/8 @ 633 nm	10 arc sec	2.1	0.5~1.2(±0.1)atm%	< λ/10 @ 632.8 nm	polished/etched polished/polished	TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um
BiB3O6 (BIBO)	25.4mm 50.8mm 76.5mm 100mm		X Y Z cut	AR/HR/PR	> λ/8 @ 633 nm	10 arc sec	2.1	0.5~1.2(±0.1)atm%	< λ/10 @ 632.8 nm	polished/etched polished/polished	TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um
钛宝石(Ti:sappire）红宝石(Cr:sappire	25.4mm 50.8mm 76.5mm 100mm	Ti/Cr	C A M cut	AR/HR/PR	> λ/8 @ 633 nm	10 arc sec	2.1	0.5~1.2(±0.1)atm%	< λ/10 @ 632.8 nm	polished/etched polished/polished	TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um
Yb:KGd(WO4)	25.4mm 50.8mm 76.5mm 100mm	镱(Yb)	X Y Z cut	AR/HR/PR	> λ/8 @ 633 nm	10 arc sec	2.1	0.5~1.2(±0.1)atm%	< λ/10 @ 632.8 nm	polished/etched polished/polished	TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um
Nd:KGd(WO4)	25.4mm 50.8mm 76.5mm 100mm	Nd(钕)	X Y Z cut	AR/HR/PR	> λ/8 @ 633 nm	10 arc sec	2.1	0.5~1.2(±0.1)atm%	< λ/10 @ 632.8 nm	polished/etched polished/polished	TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um
三硼酸锂（LBO）偏硼酸钡（BBO）	25.4mm 50.8mm 76.5mm 100mm		X Y Z cut	AR/HR/PR	> λ/8 @ 633 nm	10 arc sec	2.1	0.5~1.2(±0.1)atm%	< λ/10 @ 632.8 nm	polished/etched polished/polished	TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um
偏硼酸钡（BBO）	25.4mm 50.8mm 76.5mm 100mm		X Y Z cut	AR/HR/PR	> λ/8 @ 633 nm	10 arc sec	2.1	0.5~1.2(±0.1)atm%	< λ/10 @ 632.8 nm	polished/etched polished/polished	TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um
TSAG	25.4mm 50.8mm 76.5mm 100mm				> λ/8 @ 633 nm	10 arc sec	2.1	0.5~1.2(±0.1)atm%	< λ/10 @ 632.8 nm	polished/etched polished/polished	TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um
TGG(铽镓石榴石	25.4mm 50.8mm 76.5mm 100mm				> λ/8 @ 633 nm	10 arc sec	2.1	0.5~1.2(±0.1)atm%	< λ/10 @ 632.8 nm	polished/etched polished/polished	TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um

GGG

25.4mm 50.8mm 76.5mm 100mm

Intrinsic

<100><110><111>

AR/HR/PR

≤0.15入/25mm

10 arc sec

1.95

0.5~1.2(±0.1)atm%

< λ/10 @ 632.8 nm

polished/etched polished/polished

TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um

(Nd:GGG)

25.4mm 50.8mm 76.5mm 100mm

Nd(钕)

<100><110><111>

AR/HR/PR

≤0.15入/25mm

10 arc sec

1.95

0.5~1.2(±0.1)atm%

< λ/10 @ 632.8 nm

polished/etched polished/polished

TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um

(Yb:GGG)

25.4mm 50.8mm 76.5mm 100mm

镱(Yb)

<100><110><111>

AR/HR/PR

≤0.15入/25mm

10 arc sec

1.95

0.5~1.2(±0.1)atm%

< λ/10 @ 632.8 nm

polished/etched polished/polished

TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um

YAG

25.4mm 50.8mm 76.5mm 100mm

Intrinsic

<100><110><111>

AR/HR/PR

≤0.125入/25mm

10 arc sec

1.82

0.5~1.2(±0.1)atm%

< λ/10 @ 632.8 nm

polished/etched polished/polished

TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um

(Nd:YAG )

25.4mm 50.8mm 76.5mm 100mm

Nd(钕)

<100><110><111>

AR/HR/PR

≤0.125入/25mm

10 arc sec

1.82

0.5~1.2(±0.1)atm%

< λ/10 @ 632.8 nm

polished/etched polished/polished

TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um

(Er:YAG )

25.4mm 50.8mm 76.5mm 100mm

Er

<100><110><111>

AR/HR/PR

≤0.125入/25mm

10 arc sec

1.82

0.5~1.2(±0.1)atm%

< λ/10 @ 632.8 nm

polished/etched polished/polished

TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um

(Yb:YAG )

25.4mm 50.8mm 76.5mm 100mm

镱(Yb)

<100><110><111>

AR/HR/PR

≤0.125入/25mm

10 arc sec

1.82

0.5~1.2(±0.1)atm%

< λ/10 @ 632.8 nm

polished/etched polished/polished

TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um

YVO4

25.4mm 50.8mm 76.5mm 100mm

Intrinsic

<100><110><111>

AR/HR/PR

≤0.25入/25mm

10 arc sec

2.1

0.5~1.2(±0.1)atm%

< λ/10 @ 632.8 nm

polished/etched polished/polished

TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um

(Nd:YVO4)

25.4mm 50.8mm 76.5mm 100mm

Nd(钕)

<100><110><111>

AR/HR/PR

≤0.25入/25mm

10 arc sec

2.1

0.5~1.2(±0.1)atm%

< λ/10 @ 632.8 nm

polished/etched polished/polished

TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um

(Er:YVO4)

25.4mm 50.8mm 76.5mm 100mm

Er

<100><110><111>

AR/HR/PR

≤0.25入/25mm

10 arc sec

2.1

0.5~1.2(±0.1)atm%

< λ/10 @ 632.8 nm

polished/etched polished/polished

TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um

(Yb:YVO4)

25.4mm 50.8mm 76.5mm 100mm

镱(Yb)

<100><110><111>

AR/HR/PR

≤0.25入/25mm

10 arc sec

2.5

0.5~1.2(±0.1)atm%

< λ/10 @ 632.8 nm

polished/etched polished/polished

TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um

磷酸钛氧钾(KTP)

25.4mm 50.8mm 76.5mm 100mm

X Y Z cut

AR/HR/PR

> λ/8 @ 633 nm

10 arc sec

2.1

0.5~1.2(±0.1)atm%

< λ/10 @ 632.8 nm

polished/etched polished/polished

TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um

KDP(KH2 PO4)

25.4mm 50.8mm 76.5mm 100mm

X Y Z cut

AR/HR/PR

> λ/8 @ 633 nm

10 arc sec

2.1

0.5~1.2(±0.1)atm%

< λ/10 @ 632.8 nm

polished/etched polished/polished

TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um

Lithium Triborate (LiB3O5 , LBO)

25.4mm 50.8mm 76.5mm 100mm

X Y Z cut

AR/HR/PR

> λ/8 @ 633 nm

10 arc sec

2.1

0.5~1.2(±0.1)atm%

< λ/10 @ 632.8 nm

polished/etched polished/polished

TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um

Beta-Barium Borate (β-BaB2O4,BBO)

25.4mm 50.8mm 76.5mm 100mm

X Y Z cut

AR/HR/PR

> λ/8 @ 633 nm

10 arc sec

2.1

0.5~1.2(±0.1)atm%

< λ/10 @ 632.8 nm

polished/etched polished/polished

TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um

BiB3O6 (BIBO)

25.4mm 50.8mm 76.5mm 100mm

X Y Z cut

AR/HR/PR

> λ/8 @ 633 nm

10 arc sec

2.1

0.5~1.2(±0.1)atm%

< λ/10 @ 632.8 nm

polished/etched polished/polished

TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um

BiB3O6 (BIBO)

25.4mm 50.8mm 76.5mm 100mm

X Y Z cut

AR/HR/PR

> λ/8 @ 633 nm

10 arc sec

2.1

0.5~1.2(±0.1)atm%

< λ/10 @ 632.8 nm

polished/etched polished/polished

TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um

钛宝石(Ti:sappire）
红宝石(Cr:sappire

25.4mm 50.8mm 76.5mm 100mm

Ti/Cr

C A M cut

AR/HR/PR

> λ/8 @ 633 nm

10 arc sec

2.1

0.5~1.2(±0.1)atm%

< λ/10 @ 632.8 nm

polished/etched polished/polished

TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um

Yb:KGd(WO4)

25.4mm 50.8mm 76.5mm 100mm

镱(Yb)

X Y Z cut

AR/HR/PR

> λ/8 @ 633 nm

10 arc sec

2.1

0.5~1.2(±0.1)atm%

< λ/10 @ 632.8 nm

polished/etched polished/polished

TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um

Nd:KGd(WO4)

25.4mm 50.8mm 76.5mm 100mm

Nd(钕)

X Y Z cut

AR/HR/PR

> λ/8 @ 633 nm

10 arc sec

2.1

0.5~1.2(±0.1)atm%

< λ/10 @ 632.8 nm

polished/etched polished/polished

TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um

三硼酸锂（LBO）偏硼酸钡（BBO）

25.4mm 50.8mm 76.5mm 100mm

X Y Z cut

AR/HR/PR

> λ/8 @ 633 nm

10 arc sec

2.1

0.5~1.2(±0.1)atm%

< λ/10 @ 632.8 nm

polished/etched polished/polished

TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um

偏硼酸钡（BBO）

25.4mm 50.8mm 76.5mm 100mm

X Y Z cut

AR/HR/PR

> λ/8 @ 633 nm

10 arc sec

2.1

0.5~1.2(±0.1)atm%

< λ/10 @ 632.8 nm

polished/etched polished/polished

TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um

TSAG

25.4mm 50.8mm 76.5mm 100mm

> λ/8 @ 633 nm

10 arc sec

2.1

0.5~1.2(±0.1)atm%

< λ/10 @ 632.8 nm

polished/etched polished/polished

TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um

TGG(铽镓石榴石

25.4mm 50.8mm 76.5mm 100mm

> λ/8 @ 633 nm

10 arc sec

2.1

0.5~1.2(±0.1)atm%

< λ/10 @ 632.8 nm

polished/etched polished/polished

TTV < 5um TIR <3um STIR < 2um BOW < 10um Warp < 20um
